Find settings by selecting your 3D printer

EasyCast HD Brown

25µm Profile

EasyCast HD Violet

50μm

Curing Time: 15s

Base Settings: 90

Base: 2 Rest: 10s

30μm

Curing Time: 12.5s

Base Settings: 90s

Base: 2

Rest: 10s

50μm

  • Curing Time: 11s
  • Base Settings: 90
  • Base: 3
  • Rest: 10s

30μm

  • Curing Time: 12.5s
  • Base Settings: 90s
  • Base: 3
  • Rest: 10s

EasyCast HD Brown – B9Creator

  • Select Emerald Profile – Select Emerald Profile and change base curing to 1.34s

EasyCast HD Brown – B9Core

  • Select Emerald Profile

EasyCast HD 02 – B9 Core

  • Contact Info@resinworks3D.com for custom profile

EasyCast HD Brown & EasyCast HD 02

  • Use WIC 100 or PIC 100 Profile

EasyCast HD SLA Amber

Use open mode and select Castable V2 Profile

EasyCast HD Brown

30μm

Curing Time: 4.5

Base Curing: 50

Base: 1

Buffer: 2

50μm

Curing Time: 6.5

Base Curing: 50

Base: 1

Buffer: 2

EasyCast HD 02

30μm

Curing Time: 3

Base Curing: 40

Base: 1

Buffer: 2

50μm

Curing Time: 4.5

Base Curing: 40

Base: 1

Buffer: 2

Dental Cast HD

30μm

Curing Time: 3

Base Curing: 40

Base: 1

Buffer: 2

50μm

Curing Time: 4.5

Base Curing: 40

Base: 1

Buffer: 2

Dental Model HD

30μm

Curing Time: 1.5

Base Curing: 40

Base: 1

Buffer: 2

50μm

Curing Time: 1.7

Base Curing: 40

Base: 1

Buffer: 2

EasyCast HD Violet

Phrozen 3D Shuffle (Profile)

30μm profile (Click Here)

50μm profile (Click Here)

Phrozen 3D Shuffle 2019 ParaLED 2.0  (Profile)

30μm profile (Click Here)

50μm profile (Click Here)

Phrozen Shuffle 4K  (Profile)

30μm profile (Click Here)

50μm profile (Click Here)

Screenshot

EasyCast HD Brown

  • Contact Emil at info@junction3d.com

EasyCast HD Brown

  • Select Grey Profile

Select your material from the tab below

MiiCraft

30μm

  • Curing Time: 4.5
  • Base Curing: 50
  • Base: 1
  • Buffer:  2

MiiCraft

50μm

  • Curing Time: 6.5
  • Base Curing: 50
  • Base: 1
  • Buffer:  2

Asiga

Solus

  • Select Resinworks3D Profile

Envisiontec

  • Select Default Settings

MoonRay

  • Select Grey Profile

B9Creator v1.2

30μm

  • Select Emerald Profile and change base curing to 1.34s

 B9Core

  • Select Emerald Profile

Anycubic Photon

50μm

  • Curing Time: 15s
  • Base Settings: 90
  • Base: 1
  • Rest: 10s

30μm

  • Curing Time: 12.5s
  • Base Settings: 90s
  • Base: 1
  • Rest: 10s


Bean 3D printer by Kudo

  • Curing Time: 10-13 (12.5 Seconds should work) at 50um
  • Lift Sequence: Slow

Wanhao D7

50μm

  • Curing Time: 15s
  • Base Settings: 150
  • Base: 2
  • Rest: 1.5s

30μm

  • Curing Time: 12.5s
  • Base Settings: 150s
  • Base: 2
  • Rest: 1.5s

These are suggested curing times based on our internal printers. You may need to adjust +/- 1 to 2 seconds to curing time as LCD drivers have varying intensities.

Phrozen 3D Shuffle (Profile)

30μm profile (Click Here)

50μm profile (Click Here)

Phrozen 3D Shuffle 2019 ParaLED 2.0  (Profile)

30μm profile (Click Here)

50μm profile (Click Here)

Phrozen Shuffle 4K  (Profile)

How to Import Into PZSlice (Image and Profiles)


Profile for 30μm and 50μm

Settings for Web (Manual Input)

Settings

Anycubic Photon

50μm

  • Curing Time: 15s
  • Base Settings: 90
  • Base: 2
  • Rest: 10s

30μm

  • Curing Time: 12.5s
  • Base Settings: 90s
  • Base: 2
  • Rest: 10s

Anycubic Photon S

50μm

  • Curing Time: 11s
  • Base Settings: 90
  • Base: 3
  • Rest: 10s

30μm

  • Curing Time: 12.5s
  • Base Settings: 90s
  • Base: 3
  • Rest: 10s


Wanhao D7

50μm

  • Curing Time: 15s
  • Base Settings: 150
  • Base: 2
  • Rest: 1.5s

30μm

  • Curing Time: 12.5s
  • Base Settings: 150s
  • Base: 2
  • Rest: 1.5s

MiiCraft

30μm

  • Curing Time: 3
  • Base Curing: 40
  • Base: 1
  • Buffer:  2

MiiCraft

50μm

  • Curing Time: 4.5
  • Base Curing: 40
  • Base: 1
  • Buffer:  2

MiiCraft

30μm

  • Curing Time: 3
  • Base Curing: 40
  • Base: 1
  • Buffer:  2

MiiCraft

50μm

  • Curing Time: 4.5
  • Base Curing: 40
  • Base: 1
  • Buffer:  2

MiiCraft

30μm

  • Curing Time: 1.5
  • Base Curing: 40
  • Base: 1
  • Buffer:  2

MiiCraft

50μm

  • Curing Time: 1.7
  • Base Curing: 40
  • Base: 1
  • Buffer:  2
